Enhance Performance and Duration with Our Titanium Diaphragm for Sonic Horn
Maximize efficiency and longevity of your sonic horn systems with our high-performance titanium diaphragm. Designed for various industrial applications, our titanium diaphragm is ideal choice for demanding working environments.
As an acoustic cleaning system, sonic horn or sonic soot blower uses an oscillating diaphragm to generate sound wave. In repeat operation day after day, the diaphragm would be worn, broken or deformed, then sound generator would lose its function to generate low frequency wave.
Available brand & model
Brand: Kockum, Martin 38798, GE B100187, BHA, etc.
Model: IKT230/170, AC-75, DC-75, SH-75, D-75, SQ-100, etc.
Specification
Thickness: 1.4, 1.5, 1.6, 1.8, 2.0mm
Diameter: 150-240mm.
Above is the popular specification, we can customize sonic horn diaphragm based on drawing provided by clients.
Material
Titanium TC 4, GR 2, GR 4, GR 5.
Standards
GB/T 3621-2007，GB/T 2965-2007，GB/T 3625-2007, ASTM B 265
Mechanical properties
Tensile strength: ≥895Mpa
Yield strength: ≥825MPa
Elongation: ≥10%
Reduction of area: ≥20%
Features
- Top level fabrication
Burr-free edge, flat & smooth surface by surface treatment like acid pickling, polishing, etc.
- Unmatched durability
Made from high-grade titanium, our diaphragm with good elasticity is built to withstand extreme temperatures, high pressures, and corrosive environments, ensuring long-term reliability.
- Superior acoustic performance
Titanium material provides excellent vibration characteristics, enabling precise and efficient sound wave generation for optimal sonic horn performance.
- Corrosion Resistance
Titanium’s natural resistance to corrosion makes our diaphragm ideal for use in harsh industrial environments, including chemical plants, marine applications, and power generation facilities.
- Lightweight and Strong
Titanium’s high strength-to-weight ratio ensures robust performance without adding unnecessary weight to your sonic horn system.
